380V دیوال نصب شوی هرمونیک فلټر

The 380V Wall-mounted Active Harmonic Filter (AHF) offers a robust solution for harmonic mitigation in three-phase four-wire (3P4W) and three-phase three-wire (3P3W) 380V power systems. Employing advanced DSP+CPLD digital control and a three-level topology, this space-saving unit delivers precise harmonic current compensation. Key features include a wide harmonic filtering range (2nd to 50th harmonic), a high filtering rate (up to 95%), and a modular design for convenient parallel connection and maintenance. Available in various current ratings (25A to 150A), the 380V Wall-mounted AHF ensures stable and efficient power quality in demanding industrial environments.

Model description:

Features:

● Use DSP+CPLD all digital control core, three-level topology technology, advanced harmonic detection algorithm and PWM control strategy to achieve accurate compensation of harmonic current.
● Adopt modular design, which facilitates parallel connection of multiple modules, takes up little space and is easy to maintain.
● The structural design of independent air ducts and independent warehouses ensures the stable operation of the equipment.
● It can filter harmonics in a wide range of harmonics, from 2 to 50 harmonics, and solve the problem of three-phase unbalance at the same time.
● The harmonic filtering rate is high. If the capacity allows, the harmonic current filtering rate can be as high as 95%. Set 100% current limiting output to ensure long-term stable operation of the equipment.

Applications:

380V Wall-mounted Active Harmonic Filters are essential for maintaining power quality in a range of industrial applications:

● Industrial Automation: Protecting sensitive automation equipment and ensuring reliable operation of variable frequency drives (VFDs), robotics, and other critical loads.
● Manufacturing Plants: Improving power quality and reducing energy costs by minimising harmonic distortion.
● Data Centers: Providing clean power for critical IT infrastructure and preventing data loss due to power fluctuations.
● Oil and Gas Industry: Ensuring the reliable operation of pumps, compressors, and other essential equipment in harsh environments.
● Renewable Energy Systems: Integrating renewable energy sources into the grid while maintaining power quality and stability.

380V Wall-mounted Active Harmonic Filters provide a reliable and effective solution for optimising power quality in three-phase 380V applications.

Technical Parameters:

Model& Specification:
